| Rated Voltage | 24V |
| Rated Current | 6.25A |
| Rated Power | 150W |
| Line Regulation | ±1% |
| Load Regulation | ±1% |
| Voltage Tolerance [3] | ± 5% |
| Ripple & Noise (Max.) [2] | 720mVp-p |
| Setup, Rise Time, at Full Load [4] | 500ms, 100ms/230VAC at full load |
| Input Voltage Range | 198VAC to 264VAC |
| Frequency Range | 47 to 63Hz |
| Power Factor (Min. / Typ.) | 0.95 / 0.98 |
| THD (Typ. / Max.) | 5% / 8% |
| Efficiency (Min.) | 93% |
| AC Current (Max. Load) | 0.9A |
| Inrush Current (Typ.) | 70A / 230VAC; Twidth = 450us |
| Max. No. of PSUs on Circuit Breaker | B10: 4, B16: 7, C10: 6, C16: 11, D10: 9, D16: 14 |
| No Load Power Consumption (Typ. / Max.) | 0.45W / 0.5W |
| Protections | Overload, Short Circuit, Over Voltage, Over Temperature |
| Working Environment | -20°C to +45°C, 10 to 90% RH non-condensing |
| Storage Temperature and Humidity | -40°C to +85°C, 5 to 95% RH non-condensing |
| Safety Standards | Compliance to EN61347-1, EN61347-2-13 |
| EMC Emission | Compliance to EN55015 |
| EMC Immunity | Compliance to EN61547 |
| Harmonic Current | Compliance to EN61000-3-2 Class C |
| Other Regulations | Compliance to Commission Regulation (EU) 2019/2020 |
| Electric Strength | I/O: 3750VAC / 5mA, 60s |
| Insulation Resistance | I/O: >= 10M? / 500VDC |
| TC tc | 85°C |
| Dimensions (L x W x H) | 336.6 x 30 x 18.2mm |
| Lifetime | 30,000 hours / 230VAC, full load, tc = 75°C |
| MTBF | 200,000 hours / 230VAC, full load, ta = 25°C |
| Weight and Packing | N.W.: 0.23kg/pc; G.W.: 0.32kg/pc.; 20pcs/carton; Carton dimensions and weight: 355 x 180 x 165mm; N.W.: 4.5kg; G.W.: 6.5kg |
| EAN Code | 5902135154595 |
