032066
Artikel nr. |
032066 |
EAN |
7350143032066 |
Salgs- og leveringsbetingelser
14-dages pengene-tilbage garanti
Levering: 2-3 hverdage
Beskrivelse
.
Dokumenter
Specifikationer
| Output Voltage | 9-42Vdc |
| Flicker Index | IEC-Pst <=1, CIE SVM <=0.4 Complies with flicker-free standard (IEEE Std 1789-2015) |
| Current Tolerance | ±5% |
| Temperature Drift | ±10% |
| Start-up Time | <3S@230Vac |
| Input Voltage | 220-240Vac (voltage limit: 198-253Vac) |
| DC Input Voltage | 176-280Vdc |
| Input Frequency | 47-63Hz |
| Input Current | 0.3A max. |
| PF | >0.90@230Vac full load |
| THD | <20% |
| Efficiency | >83% |
| Inrush Current | 60A&2600uS@230Vac |
| Leakage Current | <=0.5mA |
| Standby Power Consumption | <2W (dim to off) |
| Open Circuit | Open-circuit voltage <=59Vdc |
| Short Circuit | Auto-recovery |
| Operating Temperature | –20 ? C~+45?C |
| Operating Humidity | 20-90%RH (without condensation) |
| Storage Temperature/Humidity | –40?C~+80?C (6 months in Class I environment); 10-90%RH (without condensation) |
| Atmospheric Pressure | 86-106kPa |
| EAN | 7350143032066 |
