Shelly Pro RGBWW PM
Article No. |
268216 |
EAN |
3800235268216 |
Terms and Conditions
14-day money-back guarantee
Shipping: 2-3 Business Days
Descriptions
Shelly Pro RGBWW PM: The Pro Controller for Your Smart Lighting Take your lighting to the next level with Shelly Pro RGBWW PM – a professional and DIN-rail mountable LED controller that combines advanced color control with precise power metering. This powerful device is designed to meet the needs of both installers and the discerning home automation enthusiast, offering outstanding control over your RGBWW (RGB + Warm White + Cold White) LED strips.
Full Spectrum of Light and Powerful Control
With Shelly Pro RGBWW PM, you not only get control over millions of colors (RGB), but also the ability to fine-tune white shades with both dedicated warm white and cold white channels (WW/CW). This provides unparalleled flexibility to create everything from vibrant party moods to perfect task lighting or relaxing evening ambiance.
Key Features that Impress:
- Built-in Power Metering: Keep full track of your energy consumption! Monitor in real-time how much power your connected LED strips are drawing directly in the Shelly app, helping you optimize your energy usage.
- DIN-Rail Mounting: Specifically designed for easy and secure installation in your electrical panel, providing a clean and organized setup.
- Flexible Connectivity Options: Connect via LAN (Ethernet) for the most stable connection, or use Wi-Fi for wireless flexibility. Plus, Bluetooth is available for quick and easy initial setup.
- RGBWW Support: Complete control over red, green, blue, warm white, and cold white LED channels for endless color and white tone possibilities.
- Scheduling & Scripting: Create advanced lighting schedules based on time, sunrise/sunset, or even custom scripts for complex automation scenes.
- Cloud-Free Operation & Local Control: Enjoy full functionality even without internet connection thanks to local control via MQTT, CoAP, and REST API, providing robustness and data privacy.
- Broad Compatibility: Seamlessly integrates with popular smart home systems like Google Home, Amazon Alexa, and Home Assistant.
Ideal for Projects Demanding Precision
Shelly Pro RGBWW PM is the obvious choice for those seeking a reliable and feature-rich solution for larger lighting projects. Perfect for:
- Professional Installations: Restaurants, shops, offices, or public environments requiring advanced and reliable lighting control.
- Home Automation Enthusiasts: Take your smart home lighting to new heights with full control and advanced automation possibilities.
- Custom Lighting Systems: Where power metering and precise color and white tone control are crucial.
Shelly Pro RGBWW PM is not just a controller – it's your key to creating dynamic, energy-efficient, and perfectly customized lighting environments.
Files
Specifications
| Physical Attributes | |
| Size (HxWxD) | 94x19x69 ±0.5 mm (3.70x0.75x2.71 ±0.02 inches) |
| Weight | 61 g (2.15 oz) |
| Screw Terminals Max Torque | 0.4 Nm (3.54 lbin) |
| Conductor Cross Section | 0.5 to 2.5 mm² / 20 to 14 AWG (green connector), 0.5 to 1.5 mm² / 20 to 16 AWG (blue connectors) |
| Conductor Stripped Length | 6 to 7 mm / 0.24 to 0.28 in (green connector), 5 to 6 mm / 0.20 to 0.24 in (blue connectors) |
| Mounting | DIN rail |
| Shell Material | Plastic |
| Shell Color | Yellow |
| Environmental Conditions | |
| Ambient Working Temperature | -20 °C to 40 °C (-5 °F to 105 °F) |
| Humidity | 30 % to 70 % RH |
| Max. Altitude | 2000 m (6562 ft) |
| Electrical Parameters | |
| Power Supply | 12-24 VDC |
| Power Consumption | < 1.5 W |
| External Protection | 16 A, tripping characteristic B or C, 6 kA interrupting rating, energy limiting class 3 |
| Output Circuits Ratings | |
| Max. Switching Voltage | 24 VDC |
| Max. Switching Current | 16 A |
| Max. Control Current | 16 A (total), 6 A (per channel) |
| CCT Range | 2700K - 6500K (default, configurable to any range between 1000K and 10000K) |
| Sensors & Meters | |
| Voltmeter (DC) | 12 V - 24 V, ± 10 % |
| Voltmeter Accuracy | +/-5% (12V-24V DC) |
| Ammeter (DC) | 0 mA - 5 A, ± 10 % |
| Ammeter Accuracy | +/-5% |
| Power and Energy Meters | Active and apparent power, active and apparent energy, power factor, fundamental active and fundamental reactive energy |
| Measurement Data Storage | No |
| Internal Temperature Sensor | Yes |
| Radio Capabilities | |
| Wi-Fi Protocol | 802.11 b/g/n |
| RF Band | 2401 - 2495 MHz |
| Max. RF Power | < 20 dBm |
| Range | Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (depends on local conditions) |
| Bluetooth Protocol | 4.2 |
| RF Band | 2402 - 2480 MHz |
| Max. RF Power | < 4 dBm |
| Range | Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (depends on local conditions) |
| Microcontroller Unit | |
| CPU | ESP32-D0WDQ6 |
| Clock Frequency | 40 MHz |
| Flash | 8 MB |
| Firmware Capabilities | |
| Schedules | 20 |
| Webhooks (URL Actions) | 20 with 5 URLs per hook |
| Scripting | Yes |
| MQTT | Yes |
| Encryption | Yes |
| Advanced Schedules | Yes |
| KVS (Key-Value Store) | Yes |
| EAN | 3800235268216 |
